Environmental Friendly Static Screen Wastewater Easy Maintain Low Running Cost

Description:

A no-moving part unit that cascades solid laden slurry down a wedge wire screen to separate solids from liquids. The slurry is pumped or gravity fed into the unit’s top chamber, flows over a full-width weir and cascades down the surface of the curved screen. The liquid passes through the screens voids into a collection chamber below. Solid particles larger than the screens void size stay on the surface, and as this accumulating mass increases in weight/volume, gently slides down the screens surface, compacted and further dewatered as it travels down. At the bottom discharge chute, the solids simply drop off or in some applications, go for further dewatering by a drum or screw press unit.

Application:

Static Screen has many applications in the pretreatment of wastewater for practically any kind of industry. Performance is optimum in those applications where there is no oil, a dryness greater than that obtained even by rotary screens being achieved with this system.

1. The screening of water from the plastics, paper, textile, tanning, laundry, milk industries, and food industries, etc…

2. Tank cleaning.

3. Screening of solids after channel bar screening in urban water cleaning.

4. Recycling of water in cleaning circuits.

Technical Parameters:

Advantages:

1. Sieve screen is offered with apertures from 0.5 mm ,1mm, 1.5mm to 3 mm;

2. Passive filtration method maximizes solids removal;

3. No moving parts, easy to set up with small installation area;

4. Self-cleaning, easy to maintain, and the running cost is zero;

5. No actuating equipment, neither vibration nor noise is produced;

6. Simple structure, operation simplicity, sturdiness;

Yixing Bowee Environmental Protection Equipment Co., Ltd is established in 2010 and located in Yixing city(The most famous city in the field of wastewater treatment in China). BOWEE is an integrated environmental protection company, specialized in the wastewater & sludge treatment development. Committed to industrial wastewater treatment, domestic sewage treatment, process design for upgrading and reconstruction of wastewater treatment plant, BOWEE concentrated business on technological innovation with new product development and promotion, achieved remarkable results and gained many patents as well.

BOWEE have their own standard and professional production workshop, which covers an area of 35000m2. The sales of domestic market is about 10million USD and now we establish the new ministry of foreign trade for better development. BOWEE also have a first-class technical team. All our engineers have over ten years’ experience in the field of wastewater treatment technology. We have participated in many sewage treatment projects at local market with organizations, our advanced R&D technology with our projects have grown over the past ten years through diverse project experiences.

We regard "Humanity, Quality and Prestige" as our basic operating idea. "Technology and quality" is our main principle. We will serve our customers with our best ability to accomplish the sustainable development and usage of water resource.
