EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector

Yixing Bowee Environmental Protection Equipment Co., Ltd
Contact Now
    Buy cheap EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector from wholesalers

    Buy cheap EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector from wholesalers
    • Buy cheap EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector from wholesalers
    • Buy cheap EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector from wholesalers
    • Buy cheap EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector from wholesalers

    EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector

    Ask Lasest Price
    Brand Name : BOWEE WATER
    Model Number : BWDD
    Certification : ISO9001 CE SGS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 sets per month
    Delivery Time : 15-30days
    • Product Details
    • Company Profile

    EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector

    EPDM Silicone Fine Bubble Disc Diffuser 12" 3/4'' NPT Male Thread Connector


    Description:

    The Membrane fine bubble disc diffusers have been manufactured for more than 15 years in the aeration of industrial wastewater, municipal sewage, domestic septic tank, food process like fermentation, fish farm or shrimp farm aeration. The wastewater treatment of activated sludge and contact aeration process and aquarium will all need high Oxygen transfer rate or Oxygen transfer efficiency, OTE. and low pressure loss by the membrane.


    The reinforced EPDM or Silicone can continuously create fine bubble from slots on the membrane of disc type or tube type diffuser. The expected duty life may be over 5 years without tearing or bursting. There are other material selections of self-sink silicon rubber membrane, ceramic diffuser, air stone, and coil looking diffuser. There are also course bubble air diffuser for application of liquid mixture. The diffuser can be used for roots blower, ring blower and linear air pump. The diffuser also has advantage of much energy reduction.


    We offer OEM manufacturing with high reliability and stability of performance, efficient and effective satisfaction of your client. Let our diffuser be the best choice of your solution.


    Advantages:

    1. High strength environmentally friendly materials imported linear polyethylene plus imports pigments and a unique additive made, not fade, beautiful and durable

    2. Water Horse Hollow irrigation, with elastic buffer can absorb strong impact force, reduce traffic accidents; combined, the overall affordability of a stronger, more stable

    3. Bright colors, bulky and clear route instructions

    4. Move quick and easy installation, no machinery, cost savings, there is no damage to the road

    5. Can be done with the road camber adjustment, flexible and convenient

    6. Can be yellow flashing warning device or attach other facilities, such as billboards, signs or fences, etc., play a different role and effects

    7. Fit in any road, fork, toll stations and other places


    Applications:

    1. Municipal sewage;

    2. Various industrial wastewater treatment.

    3. Aquaculture

    4. Rivers and lakes purify water.


    Technical Parameters:

    Model

    BWDD-215

    BWDD-260

    HLDD-330

    Bubble Type

    Fine bubble

    Fine bubble

    Fine bubble

    Size

    8 inch

    10 inch

    12 inch

    MOC

    EPDM/Silicon membrane

    ABS/PP carrier plate

    EPDM/Silicon membrane

    ABS/PP carrier plate

    EPDM/Silicon membrane

    ABS/PP carrier plate

    Connector

    3/4’’ NPT male thread

    3/4’’ NPT male thread

    3/4’’ NPT male thread

    Bubble Size

    1-2mm

    1-2mm

    1-2mm

    Design Flow

    1.5-2.5m3/h

    3-4m3/h

    5-6m3/h

    Flow Range

    1-6m3/h

    1-8m3/h

    1-12m3/h

    SOTE

    ≥38% (6m submerged)

    ≥38% (6m submerged)

    ≥38% (6m submerged)

    SOTR

    ≥0.31kg O2/h

    ≥0.42kg O2/h

    ≥ 0.75kg O2/h

    SAE

    ≥8.9kg O2/kw.h

    ≥8.9kg O2/kw.h

    ≥8.9kg O2/kw.h

    Headloss

    2000-4500Pa

    2000-4300Pa

    2000-4200Pa

    Service Area

    0.2-0.64m2

    0.25-1.0m2

    0.4-1.5m2

    Service Life

    > 5 year

    > 5 year

    > 5 year


    Structure:
