    Mechanical Horizontally Rotating Drum Screen Low Power Sonsumption Energy Saving

    Ask Lasest Price
    Brand Name : BOWEE WATER
    Certification : ISO9001 CE SGS
    Price : Negotiable
    Delivery Time : 15-30days
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 sets per month
    • Product Details
    • Company Profile

    Mechanical Horizontally Rotating Drum Screen Low Power Sonsumption Energy Saving

    Mechanical Horizontally Rotating Drum Screen Low Power Sonsumption Energy Saving
    Introduction

    The External Feed Rotary Drum Screen is a machine for the fine screening of sewage coming from industrial or civil purification plants, or for the screening of process waters coming from industrial transformation plants.


    Specifications:

    • Capacity: 0-560m3/h
    • Dimension: Customized
    • Material: SS304, SS316 or Customized
    • Opening type: wedge wire or perforated
    • Opening size:0.15-5mm
    • Motor brand: First-class motor, Nord or SEW is optional

    Description

    The External Feed Rotary Drum Screen is a machine for the fine screening of sewage coming from industrial or civil purification plants, or for the screening of process waters coming from industrial transformation plants.


    The External Feed Rotary Drum Screen is used in purification plants or process water treatment plants, where it is necessary to screen a large amount of fluid, i.e. fluids coming from steam raised pipelines. It is possible to install such a machine in aerial channels or in narrow spaces thanks to its limited dimensions in relation to the obtainable capacities.


    Applications

    • Civil purification plants
    • Paper Mills
    • Food Industry
    • Chemical Industry

    Technical parameters

    Model

    Screen size

    (mm)

    Mesh size

    (mm)

    Max capacity

    (m3/h)

    Dimension

    (mm)

    Power

    (kW)

    Material

    BWSEF-300

    300*500

    0.15-5

    5-50

    760*700*1200

    0.55

    SS304,SS316

    BWSEF-400

    400*600

    0.15-5

    8-90

    860*800*1300

    0.55

    SS304,SS316

    BWSEF-500

    500*750

    0.15-5

    12-140

    1050*900*1500

    0.75

    SS304,SS316

    BWSEF-600

    600*900

    0.15-5

    17-200

    1160*1000*1500

    0.75

    SS304,SS316

    BWSEF-700

    700*1000

    0.15-5

    23-280

    1260*1100*1600

    0.75

    SS304,SS316

    BWSEF-800

    800*1200

    0.15-5
